Main Parameters

Processing Range φ3.0-φ150mm Max Length of Cut-in Mill400mm Motor For Grinding Wheel 37-45kW 4P For Guiding Wheel 4kW 6P For Cooling 0.75kW 2P Spindle Unit Spindle Roller Bearing Double Support Type Grinding Wheel Spindle Roller Bearing Double Support Type Guiding Wheel Specification of Grinding Wheel 610×405×304.8mm(Outer Diameter×Width×Bore Diameter) Specification of Guiding Wheel 330×405×203.2mm(Outer Diameter×Width×Bore Diameter) Rotational Speed Grinding Wheel1040rpm(MAX.1400rpm) Linear Speed33m/s(MAX.45m/s) Stepless Variable-frequency Speed Regulation of Guide Wheel12-200rpm Electric Control Device FANUC Numerical Control System Power Supply Voltage AC380V, Frequency 50Hz Control Voltage AC100V/110V;DC24V Tilting Angle of Guiding Wheel ﹢5°-﹣5° Floor Area 3050×3100mm(Width×Length) Machine Tool Weight About 8.5t
